Union Door Closer Size 2/3/4 Silver
Power selectable hydraulic Door Closer
Closer Size Door Width Door Weight
2 Less Than 850 mm Less Than 40 Kgs
3 Less Than 950 mm Less Than 60 Kgs
4 Less Than 1100 mm Less Than 80 Kgs
- This closer must be fitted in a vertical plane, with its body horizontal, and strictly in accordance with the fixing instructions provided.
- The following maintenance program is recommended
- Lubricate the joints in the arm assembly with good quality light machine oil
- Check all fixings are secure
- Check closing speeds are acceptable, and adjust as necessary
- Ensure the door closes from any opening angle to which it may be opened, and adjust if necessary
these checks should be carried out at least every 6 months, and at a shorter intervals for heavily used doors.
- The manufacturer takes no responsibility for problems arising from any deviation from the fixing instructions or the recommended maintenance program.
